I. Main Configuration
Main configuration:
| 1. | Diesel Engine: | ||
| Internal combustion engine: | |||
| Manufacture: | DEUTZ (made in Germany) | ||
| Manufacturing plant: | deutz ag | ||
| Model: | BF4M1013EC115KW/2300rpm (liquid cooled) | ||
| model: | |||
| Rated Power: | 115KW/2300rpm | ||
| rated power: | |||
| Cooling System: | Water-Cooled，turbo-charged | ||
| cooling system: | water cooling , pressurized | ||
| Exhaust System: | Catalytic converter with muffler | ||
| Exhaust gas purification | Three-way catalytic converter and muffler |
2. Hydraulic Powertrain:
Torque Converter and Transmission:
| Manufacture: | DANA (made in Belgium) | ||
| Manufacturing plant: | Dana Corporation | ||
| Toque converter Model: | C270 | ||
| Torque Converter Model: | |||
| Trassmion Model： | RT32000 | ||
| Gearbox model: | |||
| 3. | Drive Axle | ||
| Drive axle: | |||
| Manufacture: | China brand | ||
| Manufacturing plant: | Domestic bridge (Chinese brand) | ||
| Type: | 4-wheel Rigid axles, with fully enclosed, multiple wet | ||
| type: | discs brakes at each wheel end. | ||
| 4- wheel drive rigid drive axle with integrated wet multi-disc brakes around the wheels. |
4. Braking System
Braking System
Components: Working brake, parking brake emergency park
Composition: working brake, parking brake, emergency brake
Features: (SAHR)：These brakes are the Spring Applied,
特点： Hydraulically Released type, with fully enclosed, multiple
wet discs that are at each wheel end. brake mode spring brake,
Braking is hydraulically released, and fully enclosed multi-disc friction plates are integrated at each wheel end.
5. Hydraulic System
Hydraulic system
Components: Working system, steering system, braking system,
Composition: charging system working system steering system brake system oil replenishment system
6. Oscillation Angle:±8°, Slewing bearing mounted on rear frame
ADD : Room 413. Fudengjia Building, No. 309, Heyang Road, Qingdao, Shandong, China
WEBSITE: www.zongdamining.com EMAIL: marketing@zongdamachinery.com;
AI. Main Technical Parameter:
The main technical parameters:
1. Working Capacities:
Working performance:
| Dead Weight: | 15500KG±200KG | |||
| Total Weight: | ||||
| Rated Payload: | 12000KG | |||
| Rated load capacity: | ||||
| Dimension (tramming): | 8250*1980*2300mm | |||
| Dimensions (shipping state) | ||||
| Carriage Volume:: | 6 m³ (SAE Heaped) | |||
| Compartment volume: | ||||
| Carriage Dumping Angle: | 70° | |||
| Car unloading angle: | ||||
| Wheelbase: | 4270mm | |||
| Wheelbase : | ||||
| Min. Ground Clearance: | 280mm | |||
| Minimum ground clearance: | ||||
| Carriage Oscillation Angle: | ±8° | |||
| Carriage swing angle: | ||||
| Articulated Steering Angle: | ±40° | |||
| Steering angle: | ||||
| Min. Steering Radius: | Inter ( inner side ): | Outer ( outside ): | ||
| Minimum turning radius: | 4420±150 mm | 7350±150 mm | ||
| 2. | Carriage Motion Times | |||
| homework exercise time | ||||
| Raising Time Hopper Lifting Time | 10 s | |||
| (full load) | ||||
| Lowering Time Hopper fall back time | 10.5 s | |||
| (no load) | ||||
| Operation Capacity | ||||
| operating capacity | ||||
| Max. Attraction Force: | 146KN |
Largest traction:
ADD : Room 413. Fudengjia Building, No. 309, Heyang Road, Qingdao, Shandong, China
WEBSITE: www.zongdamining.com EMAIL: marketing@zongdamachinery.com;
Crawling ability:
First Gear::
1 file:
Second Gear:
2 files:
Third Gear:
3 gears:
Electric System
5. Electrical system:
Working Voltage:
Operating Voltage:
Steering System
6. Steering:
Feature:
Features:
7. Options : other options
25% ( first gear first gear)
0~4.8 Km/h
0~10.0 Km/h
0~19.2 Km/h
24V
Full hydraulic, centre-point articulation, power steering with two double acting cylinders. Steering controlled by joystick.
Centrally articulated, fully hydraulic power steering , driven by 2 double-acting cylinders.
Ansul Manual/Auto fire extinguishing system and automatic shutdown
Centralized lubrication system Rear Camera Parking Aid
Automatic fire extinguishing device Centralized lubrication device
Reversing camera, imaging system Cab air-conditioning system
ADD : Room 413. Fudengjia Building, No. 309, Heyang Road, Qingdao, Shandong, China
WEBSITE: www.zongdamining.com EMAIL: marketing@zongdamachinery.com
QINGDAO ZONGDA MACHINERY CO., LTD is a professional manufacture focusing on research and development, production, sale and service of underground mining machinery, a solution supplier and a mining project contractor in China with strong comprehensive strength and rich experience in mining industry.
We have more than 30 professional and experienced mining experts and engineers and 200 staff for R&D, Production, QC, After Sales Technical Support and etc.
We have fulfilled our commitment to turn knowledge into value by delivering a comprehensive range of integrated equipment and services that cost-effectively transform ore bodies into high grade mineral products for customers.
A: We produce underground mining vehicles and spare parts for metal mines.
A: Yes.
A: Our quotations usually under CIF terms include Freight and Insurance but no Tariffs.
A: 1 or 2 months usually. Yes and there are stock available sometime.
A: Our forwarder partner will arrange the proper transportation solution and can arrange the door-to-door service as well.
A: We have special and detailed warranty policy.
A: Yes.
A: TT Bank Transfer is preferred.
A: 1 to 2 months usually.
A: Yes, but only LC at sight.
A: We have both local and online technical after-salves service provided.
Depending on strong technical capability and rich experience, ZONGDA provides the EPC service to the domestic and international clients and has abundant EPC project experience in China.
