DK series truck is designed to transport the ore safely, productively and profitably in extreme conditions with high capacity, strong power and four-wheel driven.

XCMG Official Dam35u Underground Articulated Dump Truck for Sale

Share on facebook
Share on twitter
Share on linkedin

DK series truck is designed to transport the ore safely, productively and profitably in extreme conditions with high capacity, strong power and four-wheel driven.

Product Details

We continue to develop and innovate with an honest attitude and professional technology, which provides a strong guarantee for the continuous optimization of the quality of our Underground Mining Scraper WinchMaterial Air BlasterFlame Proof Mining Battery Locomotive. Safety through innovation is our promise to each other. We adhere to the principle of fairness, justice and reasonable competition, and adhere to the policy of quality first, customer first, scientific management, and strive for first-class. We have an excellent research and development team of industry elites, constantly strive to collect professional technology from all over the world, coupled with nearly harsh product quality production system and strive to provide customers with high-quality products and after-sales service.

Features

Rated load of 16t, suitable for ≥3.5×3.5m tunnel

DK series truck is designed to transport the ore safely, productively and profitably in extreme conditions with high capacity, strong power and four-wheel driven.

Central articulated steering with small turning radius.

Oscillation by slewing bearing amounted front and rear frames enable the four wheels driving at any time in the rugged rock road.

The bodies are made of high strength alloy steel plate, the chassis strength increased by 33%.

DEUTZ engine. DANA Torque Converter & Transmission.

Technical Data

Dimension 8000(±100)mm×2180(±50)mm×2250(±50)mm
Engine DEUTZ BF6M1013EC 165KW(221HP)
Torque converter DANA C270
Transmission DANA R32000
Drive axle DANA 16D
Bucket 8m³
Rated Load 16t
Unload weight 15.8t
Climbing Capacity 15°
Min.Ground Clearance 280mm
Speed 0-23.87km/h
Turning Angle ±40°
Joint angle ±8°
Min.Steering Radius 4630(±50)mm(inside)
7570(±50)mm(outside)

We constantly update production line equipment, comprehensively improve production innovation capabilities, improve product quality, and do a good job in diversified management of XCMG Official Dam35u Underground Articulated Dump Truck for Sale. You may send us emails and contact us directly. We are committed to the development of high, refined, top products. And we use ‘High efficiency, superior performance’ as business goal to achieve the development of enterprise, social service goals and further development.
